Processor dBQ DP 488 PRO
Sequencer pintar dengan LED display 2 inci, pengaturan delay 0–999 detik, output 13A per channel dan proteksi over/undervoltage. Total power 600W, koneksi RS232 dan 8 switch output. Cocok untuk kontrol listrik sistem audio skala besar.
Specification
FIR Technology
Frequency Response: 20 Hz-20 kHz, -0.3 dB
S/N Rasio : > 110 dB
Distortion (THD): <O.005 pada 1 kHz (0 dB)
Cross-talk: <100 dB below full level
Type: XLR Balance
Level Input Maximum: +18 dB
Impedance: 1M/Ω Stereo; 500 K Ω/MONO
Level Output Maksimum (bypass): +18 dB
Impedance: <500 Ω
Type: XLR Balance
Converter: 32-bit delta
Sampling Rate: 96 kHz
Appearance: Dot matrix display for parameter setting and function selection
Power Supply: AC 220V ~ 50/60 Hz FUSE F2AL/250V
Dimension (P x Lx T): 48.2 x 24.7 x 4.4 cm
Weight: 3.1 kg
